Canon Bubble Jet Printer BJ-300/330 - Programmer's Manual [antikvár]

About This Manual This manual is intended for the planner, programmer or operator who desires to customize the bubble jet printer. The Bubble Jet Printers BJ-300 and BJ-330 are compatible with the IBM Proprinter X24E/XL24E and Epson LQ850/LQ1050 printers. This manual may not be necessary when using application programs that support these printers, but is essential if you write your own printer drivers. This manual is divided into two major parts. Part I explains Mode 1: IBM Proprinter X24E/XL24E emulation. Part II explains Mode 2: Epson LQ850/LQ1050 printer emulation. BJ Printer Mode 1 Mode 2 BJ-300: 80 columns X24E emulation LQ-850 emulation BJ-330: 136 columns XL24E emulation LQ-1050 emulation Your BJ-300/330 printer can easily be set to either emulation mode by merely setting the SW-1 DIP switches as follows. Setting the SW1 DIP Switches Emulation Selection (SW 1-1, SW 1-2) SW 1-1 and 1-2 are used to select the emulation mode as shown below: For BJ-300 model For BJ-330 model SW1-1 SW 1-2 Emulation Selected SW1-1 SW 1-2 Emulation ON ON IBM Proprinter X24E ON ON IBM Proprinter XL24E ON OFF EPSON LQ850 ON OFF EPSON LQ1050 OFF ON Reserved OFF ON Reserved OFF OFF Reserved OFF OFF Reserved Notes: 1. IBM Proprinter X24E and XL24E emulations shall hereafter be referred to as Emulation Mode 1. 2. Epson LQ850 and LQ1050 emulations shall hereafter be referred to as Emulation Mode 2.
